Airport Catering Truck Load Or Unload Food And Drinks To The
Aircraft
Description:
TK-SP60 Catering Truck is designed to load/unload food and drinks to the aircraft. It
docks to the aircraft via a 4-way adjustable platform. It is
applicable for aircraft with a sill height ranges from 2750-6000mm
TECHKING is one of the largest Ground Support Equipment
manufacturer incorporated since 1999.
At TECHKING, we realize our customer's confidence is relying on us,
knowing that our equipment is dependable and reliable. We are
constantly improving and strengthening our service and products to
keep things runnning smoothly and constantly. With years of
constatnly research and development in the GSE field, TECHKING now
provides dependable and reliable GSE products in 18 series and over
50 different types to meet the full range of demands..
Adhere to the aim of optimizing cost and efficiency, TECHKING has
successfully won it's acknowlegment and aapproval by all the major
airlines and airports in China as welll as customers from 20
different countries and areas and now has grown to the leader of
ground support equipment manufacturer in China.
With our expertly trained and vastly experienced staff, TECHKING
has been providing 24/7/365 services, from manufacture to delivery
commissioning, training to after-sale services, assuring ou the
most dependable on-the-ramp performance.
Specifications:
| Chassis | ISUZU QL1180XQFRY | Van-body Inside Dimension | 6800*2360*2240mm |
| Service Range | 2750-6000 mm | Gross Vehicle Weight | 15200kg (Refrigerating Unit Included) |
| Fixed Platform | 1650*2300 mm | Overall Dimension (L*W*H) | 9725*2500*3760 mm |
| Adjustable Platform | 810*1020 mm | Refrigerating Unit | Carrier, Optional: Thermo King |
| Adjustable Platform Extend Range | 600 mm | Van-body Rated Load | 5000 KG |
| Adjustable Platform Left/right Shifting Range | 600 mm | Minimum Turning Radius | ≤9000 mm |
| Fixed Platform Load | 800KG (Uniform Load) | Ground Clearance | 190 mm |
| Van-body Lifting Speed | 0-120mm/s | Hydraulic Fluid Tank Capacity | 140L |
| Van-body Dimension (L*W*H) | 7000*2500*2400 mm | Fuel Tank Capacity | 200 L |
Highlights:
Reliable branded commercial chassis with hydraulic boosted steering
and vacuum boosted brake.
Paved with anti-slippery alluminum alloy plate, ensuring maximum
safety and duration.
Equipped with various of interlocks and protections, providing the
most safe operation.
Safety Features:
Emergency Stop Button
Emergency Platform Descend
Anti-collision Sensor
Interlock to prevent moving when vanbody lifted
Interlock to prevent vanbody lifting when stabilizers not fully
extended
Interlock to prevent vanbody descending when stabilizers not fully
retracted
Interlock to prevent staibilzers retraction when vanbody is not
fully descended
Interlock to prevent hydraulic movements unless parking brake
engaged
Emergency Manual Pump
Applicable Aircraft:
A300, A310, A320, A340, BAe146, B727, B737, B747, B757, B767 etc
