Name: 281 Seating 6494ml Bulletproof Vehicles
Brand: DIMA
Price: 1 USD

Ask Lasest Price
Brand Name :	DIMA
Model Number :	DMT5120XFD
Certification :	CCC, ISO
Price :	By negociation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	2000Units/Year
Delivery Time :	1 Month

Add to Cart

Armored Bulletproof Passenger Vehicle With Good Person Loading Capacity With ABS

Base Vehicle Specification

Catalog	Items	Data
Chassis	Chassis model	CKZ6884CDX4
	Seating capacity	28+1
	Drive model	4×2 FR
Weight	Curb weight(kg)	7600
	GVW(kg)	12200
	Max. Axle Load(front/rear) (kg)	4500/9500
Dimension	Wheelbase(mm)	5000
	Length(mm)	8780
	Width(mm)	2450
	Height(non-load)(mm)	3150
	Front Overhang (mm)	1120
	Rear Overhang (mm)	2660
Engine	Engine model	YC6J200-42
	Engine type	Vertical in line type, air-air Inter-Cooling, electronic-controlled, high-pressure common rail system Diesel Engine
	Engine Manufacturer	Yuchai Machinery Co., Ltd.
	Displacement(cc)	6494
	Max. Power(Kw/r/min)	147/2500
	Max. Torque(N.m/r/min)	730/1200-1700
	Fuel type	Diesel
	Oil tank capacity(L)	200L, aluminium ally oil tank
	Emission standard	Eruo IV
Speed	Max. Speed(km/h)	90
Suspension	Front suspension	Parabolic suspension,3 pieces of Spring, Stabilizer bar
Suspension	Rear suspension	Parabolic suspension, 4 pieces of Spring
Tyre	Tyre model	10R22.5-16PR
Ground clearance	Min. ground clearance (mm)	220
Air condition	Max. Cooling capacity (kw/h)	20000
Brake	Two-circuit air brake system, front disc with rear drum brake, Storage spring type parking brake, ABS

Ballistic Protection Details　

1 Protect Level: CEN B5

Firearms : AK47 rifle; Bullet : 7.62×39 ball ammunition;

Weight : 16.4g; Overall length: 56.0m;

Weight of gunpowder: 1.6g; Warhead dia. : 7.92 mm;

Weight of warhead: 7.9g; Speed : 710m/s

2 Bulletproof scope:

Four-side armoring of passenger compartment (verticals)

Engine, water tank, battery, fuel tank

Pillar & door post are protected with overlap

3 Bulletproof Materials:

Multilayer ballistic glass, no splinter after being shot

Vehicle body is armored with ballistic steel and (or) fiber plate

4 Run Flat:

Could drive 10km at 30-50km/h after tire shot

Product Tags:
