Bulletproof Armored Bank Vehicles

Ask Lasest Price
Brand Name :	DIMA
Model Number :	DMT5045XYCEV1-AM
Certification :	ISO9001, CCC
Price :	Negotiation
Payment Terms :	L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
Supply Ability :	2000Unit/Year
Delivery Time :	1 month

Add to Cart

Product Details
Company Profile

Bulletproof Armored Bank Vehicles

Bulletproof, Armored Cash In Transit Vehicle, Electric Vehicle Chassis, Safe And Comfort, Security Door Of Banknote Box

Description:

DMT5045XYCEV1-AM is made of JMC touring series pure electric chassis,The drive cabin and the escort compartment are bulletproof on all four sides, and the banknote compartment is riot-proof,The drive cabin and the escort compartment are bulletproof on all four sides, and the banknote compartment is riot-proof, it have very good front view with streamlined and beautiful appearance and set up a banknote transfer hole in the drive cabin, embrasures on both sides of the escort compartment, as well as a color monitoring system..

Main technical parameters

Model	DMT5045XYCEV1-AM
Chassis model	JX5040XXYTC-M5BEV Pure Electric Vehicle/JMC
Drive system	4×2
Overall dimensions L×W×H mm	5240(With Front Bumper)/5390(With Front And Rear Bumpers)×1972×2280(Manual Skylight)/2220(Electric Skylight) 5240(With Front Bumper)/5390(With Front And Rear Bumpers)×1972×2240 5240(With Front Bumper)/5390(With Front And Rear Bumpers)×1972×2080(Manual Skylight)/2025(Electric Skylight) 4888(With Front Bumper)/5040(With Front And Rear Bumpers)×1972×2280(Manual Skylight)/2220(Electric Skylight) 4888(With Front Bumper)/5040(With Front And Rear Bumpers)×1972×2080(Manual Skylight)/2025(Electric Skylight)
Banknote box dimensions L×W×H mm	1430×1680×1510 1430×1680×1460 1430×1680×1300 1080×1680×1510 1080×1680×1300
Volume (M3)	3.6 3.5 3.1 2.7 2.35
Curb weight (kg)	2540(Long body),2480(Short body)
Gross vehicle weight (kg)	3510
Rated load (including the crew) (kg)	970(Long body),1030(Short body)
Number of people allowed in the drive cabin (person)	3+3,2+3,3+2
Drive motor model	TZ260XSDA4
Drive motor rated power / speed / torque(kW/r/min/N.m)	60kW/2046/280
Peak power / speed / torque of driving motor(kW/r/min/N.m)	120kW/4500/800
Battery model	LSHD156S002P-02A-C1
Total battery energy(kwh)	58.1
Cruising range (heavy vehicle CWTVC city comprehensive working condition) (km)(km)	420
Cruising range (heavy vehicle CWTVC city comprehensive working condition) (km)	200
Charging 80% of the time (DC fast charging)(min)	40
Battery pack energy density (Wh / kg)	140
Tread(Front/Rear)(mm)	1692 / 1700
Wheelbase(mm)	2835
Ground Clearance(mm)	200
Maximum speed (Km / h)	120
Tire specifications	215/65R16C
Bulletproof level	B4-B6
