4000L Electric Lavatory Service Truck, Airport Toilet Truck,
Airport Lavatory Truck, Aviation Lavatory Service Truck
TECHKING is one of the largest Ground Support Equipment
manufacturer incorporated since 1999.
At TECHKING, we realize our customer's confidence is relying on us,
knowing that our equipment is dependable and reliable. We are
constantly improving and strengthening our service and products to
keep things runnning smoothly and constantly. With years of
constatnly research and development in the GSE field, TECHKING now
provides dependable and reliable GSE products in 18 series and over
50 different types to meet the full range of demands..
Adhere to the aim of optimizing cost and efficiency, TECHKING has
successfully won it's acknowlegment and aapproval by all the major
airlines and airports in China as welll as customers from 20
different countries and areas and now has grown to the leader of
ground support equipment manufacturer in China.
With our expertly trained and vastly experienced staff, TECHKING
has been providing 24/7/365 services, from manufacture to delivery
commissioning, training to after-sale services, assuring ou the
most dependable on-the-ramp performance.
Description:
TK-eWS40 Electric Lavatory Truck is designed to provide rising water to aircraft and drain the
lavatory waste. It is designed to provide rising water to aircraft
and drain the lavatory waste. It is consisting of electric
commercial chassis, vacuum suction system, water tank, PTO
assembly, tail-lift and electrical control system, vacuum suction
and rising water supply system etc. It is applicable to all civil
aircraft.
Specifications:
| Chassis | market-proven electric commercial chassis | Rising Water Tank Capacity | 1500 L |
| Water Flow | ≥130 L/min | Sewage Tank Capacity | 2500 L |
| Water Pressure | 0.25-0.35 Mpa | Tail-lift Service Range | 400-2800 mm |
| Pressure Gauge | 0-1.6 Mpa | Maximum Speed | 60 KM/H |
| Vacuity | 0.2 bar | Overall Dimension L*W*H: | 7500*2100*2300 mm |
Applicable Aircraft:
A300, A310, A320, A340, BAe146, B727, B737, B747, B757, B767 etc
Highlights:
Reliable market-proven electric commercial chassis, with lithium
iron phosphate battery.
Baffled and cushioned 4mm thick 0Cr18Ni9 stainless steel water
tank, less vibration and shock.
Integrated water tank assembly consisting of independent flushing
tank, sewage tank, vacuum pump circulating water tank and baffle.
Passivated and solders-removed water tank to minimize corrosion and
rust.
Equipped with a liquid level indicator, stainless centrifugal pump
and a spring driven water pipe reel.
